KEB F6 Series User Manual

Key Function Bar Description
F1 Menu Return to the File Menu
F2 FTP Go to FTP menu
F4 Delete Delete selected le
Figure 33: File operations screen
7.9 FTP mode screen
From the File Operations screen, the FTP screen connects the operator with a computer
to transfer les. When using an ethernet connection, the FTP screen is not needed to
connect to the operator.
Key Function Bar Description
F1 Menu Return to File Menu screen
F2 Flash Return to FIle Operations screen
Figure 34: FTP mode screen
7.10 Flash functions screen
This screen displays the le usage of the operator and the number of used les and
bytes. The F3 and F4 keys can be used if the password level is high enough. Formatting
the operator is not recommended as it will remove the language le. The language le
is required for the operator to function properly.
Key Function Bar Description
F1 File Return to File Menu screen
F3 Format Format the operator
(Deletes all les present on the operator)
Figure 35: Flash functions screen
45
SCREEN OVERVIEW

KEB F6 Series Specifications

General

Communication Interfaces	RS-485, Modbus RTU, CANopen
Protection	Overcurrent, overvoltage, undervoltage, short circuit
Operating Temperature	-10°C to +40°C
Humidity	Up to 95% relative humidity, non-condensing
Control Modes	sensorless vector control (ASCL), closed-loop vector control (encoder feedback)
