6.7.1 Operator system parameters (OS)
Only the meanings of the parameter values are described in the following. Value range,
data length and data type; Access mode and the default values can be taken from COM-
BIVIS.
OS00 Operator type Parameter address 0x0180
Value Description
e.g. 12700 Display of the operator type (conguration number)
• 12710 : F6 Ethernet
• 12700 : F6 default + USB
OS01 Password Parameter address 0x2181
Value Description
-1…-9 Displays the actual password level of the operator, independent of the drive controller.
Is used to enter the operator password level and is also the actual le level:
• 550 = user read-only, le level = 5
• 660 = user read/write, le level = 6
• Supervisor, le level = 7
OS02 FTP mode Parameter address 0x2386
Value Description
0...1 Activation of the FTP mode. The FTP mode can also be started via the main menu.
• 0: Inactive
• 1: Active
OS03 Startup mode Parameter address 0x2387
Value Description
0…8 The startup mode determines the display during switch on.
• 0: Main menu
• 1: Inverter parameter
• 2:
Operator parameter
• 3: Parameter saving
• 4: Download mode
• 5: Worklist mode
• 6: File operations
• 7: FTP mode
• 8: Test mode
29
