4-4 Replaceable Parts
C252,253,255-257,259-263,271,169,270 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C254 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C280,281,172,174-177,180,182,186,187 CAP, .1UF, 10%, 25V, CERAMIC C-495-.1
C285 CAP, .15UF, 20%,50V, CERAMIC C-418-.15
C286 CAP, .047U, 10%, 50V, CERAMIC C-491-.047
C288,C289 CAP, .1UF, 20%, 50V, CERAMIC C-418-.1
C293 CAP, .01UF, 20%, 50V, CERAMIC C-418-.01
C294,C284 CAP, .47, 10% 16V, CERAMIC C-565-.47
CR100,CR101,CR110,CR111 DIODE, SWITCHING, MMSD914T19 RF-112
CR104 DIODE, DUAL HSM-2822T31 RF-95
J1002 CONN, MOLEX, 3-PIN CS-772-3
J1003 CONN, RIGHT ANGLE,24PIN CS-507
J1005 SHIELDED RT. ANGLE PHONE JACK CS-981
J1006, J1013,J1015 LATCHING HEADER, FRICTON, SGL
ROW
CS-724-3
L101 EMI SUPPRESSION INDUCTOR CH-84
L103,L104,L105,L109 FERRITE CHIP 600 OHM BLM32A07 CH-62
L106,L107,L108 FERRITE CHIP 600 OHM BLM32A07 CH-62
P1007 CABLE ASSEMBLY, 26 CONDUCTOR CA-27-6
P1008 CABLE ASSEMBLY WITH GROUND
PLANE
CA-152-2B
P1009 CABLE ASSEMBLY CA-62-4B
P1010 CABLE ASSEMBLY CA-171-1A
PS100 POWER SUPPLY PS-64A
Q100-102,104-106,111,123 TRANS, NPN, MMBT3904 TG-238
Q103,107,109,110,112 TRANS, N-MOSFET, VN0605T TG-243
Q108 TRANS, PNP, MMBT3906L TG-244
Q122 TRANS, P-CHAN, MOSFET, TP0610T TG-259
R100,R169 RES, 200, 1%, 100MW, THICK FILM R-418-200
R101,112,143,150,176,177,181,186,187,189 RES, 475, 1%, 100MW, THICK FILM R-418-475
R102 RES, 6.04K, 1%, 100MW, THICK FILM R-418-6.04K
R103,155,254,163,174,185,255 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R105 RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R106,R162 RES, 16.9K, 1%, .125W, METAL FILM R-391-16.9K
R107,R158,R191,R118 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R109,110,115,120-122,126,127,129,119,227 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R111,R165 RES, 4.02K,1%, 100MW, THICK FILM R-418-4.02K
Table 4-1 (continued)
Models 2303 and 2303-PJ digital board parts list
Circuit designation Description Keithley part no.
