Replaceable Parts 4-5
R113,R156 RES, 24.3, 1%, 100MW, THICK FILM R-418-24.3
R114 RES, 332K,1%, 100MW, THICK FILM R-418-332K
R116,R167 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R117,R168 RES, 2K, 1%, 125MW, METAL FILM R-391-2K
R123,R170,R172 RES, 8.06K, 1%, .1W, THICK FILM R-418-8.06K
R124,R125,R188 RES,1K, 5% 250MW, METAL FILM R-376-1K
R128,R151,R232,R273 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R130,R225,R243 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R133 RES, 1.5K, 5%, 250MW, METAL FILM R-376-1.5K
R137 RES, 66.5K, 1%, 100MW, THICK FILM R-418-66.5K
R141 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R144,R145,R146,R149 RES, 10K, .1%, .125W, THIN FILM R-456-10K
R147,R148 RES, 20K, .1%, .125W, THIN FILM R-456-20K
R153 RES, 49.9K, 1%, 100MW, THICK FILM R-418-49.9K
R154 RES, 10M, 1%, 125MW, THICK FILM R-418-10M
R164 RES, 1M, 1%, 100MW, THICK FILM R-418-1M
R166 RES, 150K, 1%, 100MW, THICK FILM R-418-150K
R171,R180,R192,R197 RES, 100, 1%, 100MW, THICK FILM R-418-100
R175 RES, 10, 10%, 100MW, THICK FILM R-418-10
R182 RES, 1K, 1%, 125MW, METAL FILM R-391-1K
R183 RES NET TF-245
R184 RES, 1.28M, .1%, 1/8W, METAL FILM R-176-1.28M
R190,193-196,269 RES, 475, 1%, 100MW, THICK FILM R-418-475
R198 RES, 499, 1%, 100MW, THICK FILM R-418-499
R199 RES, 15k, 1%, 100MW, THICK FILM R-418-15K
R221 RES, 866, 1%, 100MW, THICK FILM R-418-866
R223,R231 RES, 10M, 1%, 125MW, THICK FILM R-418-10M
R226,R142 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R230,247,250,132,134,152,222,224,135 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R235,R238 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R236,R237 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R239 RES, 6.04K, 1%, 125MW, THIN FILM R-423-6.04K
R240,R108,R279 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R241 RES, 3.01K, 1%, 125MW, METAL FILM R-391-3.01K
R242,R252 RES, 100, 1%, 100MW, THICK FILM R-418-100
R244 RES, 82.5, 1%, 100MW, THICK FILM R-418-82.5
Table 4-1 (continued)
Models 2303 and 2303-PJ digital board parts list
Circuit designation Description Keithley part no.
