Model 2790 SourceMeter
®
Switch System User’s Manual 3-7
Figure 3-5
Voltage connections (DCV or ACV)
Connection log
Make a copy of Table 3-1 and affix it to the cover of the Model 7702. Use this to record
connection information and channel descriptions as needed.
Channel 1
HI
LO
Channel 40
HI
LO
(Channels 2–39)
+
+
DC Voltage AC Voltage
7702
