Keithley 2790 - Table 5-8 Command Sequence for Memory Patterns Test Example Using Individual Memory Pattern Recall

Model 2790 SourceMeter
®
Switch System User’s Manual 5-33
Table 5-8
Command sequence for memory patterns test example using individual memory
pattern recall
Command Sequence Description
*RST Restore GPIB defaults.
ROUT:MEM:CLE:ALL Clear all memory pattern locations.
Set up memory location 1:
ROUT:MEM:CHAN 1,(@101,114,118) Set channels 1, 14, and 18 for memory location 1.
ROUT:MEM:DEL 1,0 Set delay to 0.
ROUT:MEM:READ:STAT 1, ON Enable reading.
SENS:FUNC 'RES',(@M1) Select 2-wire ohms.
SENS:RES:RANG 100,(@M1) Select 100Ω range.
SENS:RES:NPLC 1,(@M1) Select 1 PLC.
Set up memory location 2:
ROUT:MEM:CHAN 2,(@104,114,118) Set channels 4, 14, and 18 for memory location 2.
ROUT:MEM:DEL 2,0 Set delay to 0.
ROUT:MEM:READ:STAT 2, ON Enable reading.
SENS:FUNC 'RES',(@M2) Select 2-wire ohms.
SENS:RES:RANG 100,(@M2) Select 100Ω range.
SENS:RES:NPLC 1,(@M2) Select 1 PLC.
Set up memory location 3:
ROUT:MEM:CHAN 3,(@108,115,118) Set channels 8, 15, and 18 for memory location 3.
ROUT:MEM:DEL 3,0 Set delay to 0.
ROUT:MEM:READ:STAT 3,ON Enable reading.
SENS:FUNC 'RES',(@M3) Select 2-wire ohms.
SENS:RES:RANG 100,(@M3) Select 100Ω range.
SENS:RES:NPLC 1,(@M3) Select 1 PLC.
FORM:ELEM READ Send readings only from buffer.
Recall memory locations, trigger/request readings:
ROUT:MEM:REC 1 Recall memory pattern 1.
READ? Trigger and request reading.
ROUT:MEM:REC 2 Recall memory pattern 2.
READ? Trigger and request reading.
ROUT:MEM:REC 3 Recall memory pattern 3.
READ? Trigger and request reading.
