Keithley DMM6500 Calibration Manual

Model DMM6500 6½-Digit Multimeter with Scanning Calibration and Adjustment Manual Section 2: Performance verification
DMM6500-905-01 Rev. A/July 2018 2-5
Test summary
Front-panel tests:
• DC voltage verification (on page 2-6)
• AC voltage verification (on page 2-8)
• Digitize voltage verification (on page 2-12)
• Frequency verification (on page 2-14)
• Simulated thermocouple type J temperature verification (on page 2-15)
• Simulated RTD temperature verification (on page 2-17)
• Resistance verification (on page 2-20)
• DC current verification (on page 2-24)
• Digitize current verification (on page 2-28)
• AC current verification (on page 2-30)
• Capacitance verification (on page 2-33)
• Verifying zero values using a 4-wire short (on page 2-35)
Rear-panel tests:
• DC current 10 A range verification (on page 2-37)
• Digitize current 10 A range verification (on page 2-39)
• AC current 10 A verification (on page 2-40)
Test considerations
When performing the calibration verification procedures:
• Be sure to restore factory front-panel defaults. From the front panel, select the MENU key, select
Info/Manage, and select System Reset.
• Make sure that the test equipment is warmed up for the time recommended by the manufacturer
and is connected to the DMM6500 input/output terminals.
• Make sure that the correct DMM6500 terminals are selected with the TERMINALS FRONT/REAR
switch.
• Make sure the test equipment is set up for the proper function and range.
• Do not connect test equipment to the DMM6500 through a scanner, multiplexer, or other
switching equipment.
Figure 1: VARIABLE - WARNING
The front and rear terminals of the instrument are rated for connection to circuits rated
Measurement Category II up to 300 V, as described in International Electrotechnical
Commission (IEC) Standard IEC 60664. This range must not be exceeded. Do not connect the
instrument terminals to CAT III or CAT IV circuits. Connection of the instrument terminals to
circuits higher than CAT II can cause damage to the equipment and severe personal injury.

Keithley DMM6500 Specifications

General

Resolution	6.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
AC Current Range	10 µA to 10 A
Temperature Range	-200 °C to 1820 °C
Display	5-inch capacitive touch screen
Resistance Range	100 MΩ
Frequency Range	3 Hz
Sampling Rate	1 MS/s
Connectivity	USB, LAN, GPIB (optional), TSP-Link
Memory	7 million readings
