Keithley DMM6500 Calibration Manual

Model DMM6500 6½-Digit Multimeter with Scanning Calibration and Adjustment Manual Section 2: Performance verification
DMM6500-905-01 Rev. A/July 2018 2-13
2. On the DMM6500, press the FUNCTION key, select the Digitize Functions tab, and select
Digitize Voltage.
3. On the Home screen, select the button next to Range and select 100 mV.
4. Press the MENU key.
5. Under Measure, select Settings.
6. Set the Sample Rate to 1000.
7. Set the Aperture to Auto.
8. Set the Count to 100.
9. Set the calibrator output to 0.00000 mV DC and allow the reading to settle.
10. Press the MENU key.
11. Under Measure, select Calculations.
12. Select Rel Acquire.
13. Source positive and negative full-scale and half-scale voltages, as listed in the following table.
Verify the 1 V to 100 V range settings listed in the tables below. For each voltage setting, verify
that the STATISTICS swipe screen reading for Average is within low and high limits.
The Fluke 5720A or 5730A calibrator 1000 V range 0.0 V setting is not verified.
Verify the digitize voltage 100 mV range
Description
Input
Lower limit
Upper limit
Perform relative
offset
0
n/a
n/a
Full scale (+)
0.1
9.9940E-02
1.00060E-01
Half scale (+)
0.05
4.9950E-02
5.0050E-02
Half scale (–)
-0.05
–5.0050E-02
–4.9950E-02
Full scale (–)
-0.1
–1.00060E-01
–9.9940E-02
Verify the digitize voltage 1 V range
Description
Input
Lower limit
Upper limit
Verify zero
0
–1E-04
1E-04
Full scale (+)
1
9.9960E-01
1.00040E+00
Half scale (+)
0.5
4.9975E-01
5.0025E-01
Half scale (–)
–0.5
–5.0025E-01
–4.9975E-01
Full scale (–)
–1
–1.00040E+00
–9.9960E-01
Verify the digitize voltage 10 V range
Description
Input
Lower limit
Upper limit
Verify zero
0
–1E-03
1E-03
Full scale (+)
10
9.9960E+00
1.00040E+01
Half scale (+)
5
4.9975E+00
5.0025E+00
Half scale (–)
–5
–5.0025E+00
–4.9975E+00
Full scale (–)
–10
–1.00040E+01
–9.996E+00

Keithley DMM6500 Specifications

General

Resolution	6.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
AC Current Range	10 µA to 10 A
Temperature Range	-200 °C to 1820 °C
Display	5-inch capacitive touch screen
Resistance Range	100 MΩ
Frequency Range	3 Hz
Sampling Rate	1 MS/s
Connectivity	USB, LAN, GPIB (optional), TSP-Link
Memory	7 million readings
