Keithley DMM6500 Calibration Manual

Model DMM6500 6½-Digit Multimeter with Scanning Calibration and Adjustment Manual Section 3: Adjustment
DMM6500-905-01 Rev. A/July 2018 3-17
Command parameters for a DC current adjustment
When calibrating your DMM6500 for a DC current adjustment, use the following command
parameters.
Send each command parameter twice. First, send the parameter using the setup command.
Second, send the parameter using the execute command along with the calibrator stimulus value.
The example code below uses the first line of code from the table below. Send all command
parameters using this command.
cal.adjust.step.setup("cal_DCI_10uA_fs_pos")
cal.adjust.step.execute("cal_DCI_10uA_fs_pos", <calibrator stimulus value>)
You must send the cal_TS6 first.
Command parameters
Calibrator
function
Calibrator
range
Calibrator
value
Calibrator
stimulus
value*
Reference
DMM DC
current range
cal_TS6
n/a
n/a
n/a
n/a
10 µA range (+) full scale nominal
cal_DCI_10uA_fs_pos
DC current
0.00022
0.00001
8508A
Reading
10 µA
cal_DCI_DIGI_10uA_fs_pos
DC current
0.00022
0.00001
8508A
Reading
10 µA
10 µA range (-) full scale nominal
cal_DCI_10uA_fs_neg
DC current
0.00022
-0.00001
8508A
Reading
10 µA
cal_DCI_DIGI_10uA_fs_neg
DC current
0.00022
-0.00001
8508A
Reading
10 µA
100 µA range (+) full scale nominal
cal_DCI_100uA_fs_pos
DC current
0.00022
0.0001
8508A
Reading
100 µA
cal_DCI_DIGI_100uA_fs_pos
DC current
0.00022
0.0001
8508A
Reading
100 µA
100 µA range (-) full scale nominal
cal_DCI_100uA_fs_neg
DC current
0.00022
-0.0001
8508A
Reading
100 µA
cal_DCI_DIGI_100uA_fs_neg
DC current
0.00022
-0.0001
8508A
Reading
100 µA
*Characterized step measured by the Fluke 8508A
