Keithley DMM6500 Calibration Manual

Model DMM6500 6½-Digit Multimeter with Scanning Calibration and Adjustment Manual Section 3: Adjustment
DMM6500-905-01 Rev. A/July 2018 3-21
Command parameters for an AC voltage adjustment
When calibrating your DMM6500 for an AC voltage adjustment, use the following command
parameters.
Send each command parameter twice. First, send the parameter using the setup command.
Second, send the parameter using the execute command.
The example code below uses the first line of code from the table below. Send all command
parameters using this command.
cal.adjust.step.setup("cal_ACV_100mV_1kHz_1pct")
cal.adjust.step.execute("cal_ACV_100mV_1kHz_1pct")
Command parameter
Calibrator
function
Calibrator
range
Calibrator
value
Calibrator
frequency
cal_ACV_100mV_1kHz_1pct
AC voltage
0.0022
0.001
1 kHz
cal_ACV_100mV_10Hz_fs
AC voltage
0.22
0.1
10 Hz
cal_ACV_100mV_1kHz_fs
AC voltage
0.22
0.1
1 kHz
cal_ACV_100mV_50kHz_fs
AC voltage
0.22
0.1
50 kHz
cal_ACV_100mV_100kHz_fs
AC voltage
0.22
0.1
100 kHz
cal_ACV_100mV_200kHz_fs
AC voltage
0.22
0.1
200 kHz
cal_ACV_100mV_300kHz_fs
AC voltage
0.22
0.1
300 kHz
cal_ACV_1V_1kHz_1pct
AC voltage
0.022
0.01
1 kHz
cal_ACV_1V_10Hz_fs
AC voltage
2.2
1
10 Hz
cal_ACV_1V_1kHz_fs
AC voltage
2.2
1
1 kHz
cal_ACV_1V_50kHz_fs
AC voltage
2.2
1
50 kHz
cal_ACV_1V_100kHz_fs
AC voltage
2.2
1
100 kHz
cal_ACV_1V_200kHz_fs
AC voltage
2.2
1
200 kHz
cal_ACV_1V_300kHz_fs
AC voltage
2.2
1
300 kHz
cal_ACV_10V_1kHz_1pct
AC voltage
0.22
0.1
1 kHz
cal_ACV_10V_10Hz_fs
AC voltage
22
10
10 Hz
cal_ACV_10V_1kHz_fs
AC voltage
22
10
1 kHz
cal_ACV_10V_50kHz_fs
AC voltage
22
10
50 kHz
cal_ACV_10V_100kHz_fs
AC voltage
22
10
100 kHz
cal_ACV_10V_200kHz_fs
AC voltage
22
10
200 kHz
cal_ACV_10V_300kHz_fs
AC voltage
22
10
300 kHz
cal_ACV_100V_10Hz_1pct
AC voltage
2.2
1
10 Hz
cal_ACV_100V_1kHz_1pct
AC voltage
2.2
1
1 kHz
cal_ACV_100V_50kHz_1pct
AC voltage
2.2
1
50 kHz
cal_ACV_100V_100kHz_1pct
AC voltage
2.2
1
100 kHz
cal_ACV_100V_200kHz_1pct
AC voltage
2.2
1
200 kHz
cal_ACV_100V_300kHz_1pct
AC voltage
2.2
1
300 kHz
cal_ACV_100V_1kHz_fs
AC voltage
220
100
1 kHz
cal_ACV_700V_10Hz_1pct
AC voltage
22
7
10 Hz
cal_ACV_700V_1kHz_1pct
AC voltage
22
7
1 kHz
cal_ACV_700V_50kHz_1pct
AC voltage
22
7
50 kHz
