Dust collection container door
Side maintenance entrance to
fan area
Connection socket for
external operating element
Connecting sleeve for 9 mm
compressed air connection
6- and 12-pole socket for
connecting extensions
Maintenance cover, fan area
CEE plug connection housing
power supply (coupling
included)
Exhaust opening (optional
transition piece for exhaust
air)
Suction-side connection box
Maintenance cover, filter area
Maintenance cover for
compressed air vessel + safety
valve
Tab. 47: Positions on the product
Fig. 64: Connection panel
3.2 Functional description of extraction capacity regulation
(optional)
Products with automatic extraction capacity regulation are fitted with
systems that keep the extraction capacity constant according to
