7.2.11 Access to compressed air vessel + compressed air safety
valve
Access to compressed air vessel
Fig. 106: Access to compressed air vessel
Item
Description
Item
Description
1
Cover plate
3
Compressed air vessel
2
Cover plate
4
Compressed air vessel
nameplate
Tab. 79: Access to compressed air vessel
The product has one or more compressed air vessels.
To gain access to the compressed air vessel(s) (item 3), the side cover plate
(item 2) must be removed.
