1502756-02 - 138 -
5.7 Wiring diagram
5.7.1 General information on the wiring diagram
NOTE
Mains supply connection
On site, ensure the correct pre-fusing and the correct cable cross-section
of the mains supply connection cable.
Rated current: See nameplate/data sheet
Rated current
Back-up fuse
0-9 A
Circuit breaker 3x16 A category C
9-12 A
Circuit breaker 3x16 A category C
12-22 A
Circuit breaker 3x32 A category C
22-35 A
Circuit breaker 3x50 A category C
35-45 A
Circuit breaker 3x63 A category C
45-55 A
Circuit breaker 3x80 A category C
55-70 A
Circuit breaker 3x100 A category C
70-85 A
Circuit breaker 3x125 A category C
Tab. 52: Selecting the pre-fusing
Product connection variants
Connection
type
Product without
extraction capacity
regulation
Product with extraction
capacity regulation
CEE connection
plug on the
product
3420-3485
322014-326528
-
Terminal strip
connection for
control cabinet,
product
34110-34270
328528-32180218
3420-3485
34110-34270
322014-326528
328528-32180218
Tab. 53: Connection variants
