Colours of the cable wires
Color
Description
Color
Description
BK
Black
BU
Blue
BN
Brown
WH
White
GR
Grey
GN/YE
Green/Yellow
SH
Cable shielding
Tab. 54: Wire colours
5.7.2 Product with plug connection
Product is supplied ready to plug in and can be operated immediately.
To do this, connect the mains supply cable provided by the customer to
the CEE plug of the product.
5.7.3 Product with connection terminals
Selection of the mains supply connection cable
Rated
current
Mains supply
connection cable
Rated
current
Mains supply
connection cable
0-9 A
5 x 1.5 mm²
35-45 A
5 x 16 mm²
9-12 A
5 x 2.5 mm²
45-55 A
4 x 25 mm²
12-22 A
5 x 6 mm²
55-70 A
4 x 35 mm²
22-35 A
5 x 10 mm²
70-85 A
4 x 50 mm²
Tab. 55: Selection of the mains supply connection cable
NOTE
Rated current: See nameplate/data sheet.
Dimensioning: Mains supply connection cable up to a maximum cable
length of 50 metres.
