1. Connecting the inlet-side connection box
Now fit the inlet-side connection box to the product. The necessary
bolts are provided in a bag inside the product. The connection box can
be fitted to the left-hand or right-hand side of the product depending
on local conditions. Close off the connection panel opening not selected
with the end cap provided.
2. Connecting the compressed air supply
Now connect an on-site compressed air hose with an internal diameter
of 9 mm. To do this, the hose is pressed onto the grommet and fixed
with a band clamp. The hose and band clamp are not included in
delivery.
3. Adjusting the operating pressure
The pressure at the compressed air maintenance unit has been pre-set
to 5–6 bar by the manufacturer, but must be readjusted on site.
4. Adjusting the lifting device/dust collection container pressure
Also check that the specified value of 2.5 bar has been set on the
compressed pressure regulator, readjust if necessary. The value may not
exceed 3.0 bar.
5. Connecting the power supply
Now connect the product with a CEE connector plug. CEE plug
included in delivery. When doing so, ensure that the feed line is
correctly fused and that the correct phase rotation direction has been
selected. If the phase rotation direction is incorrect, an error message
will appear on the operating control. Please also follow the information
and notices in the circuit diagram.
