EN
1502756-02 - 174 -
Fig. 97: Access to the safety filter
Fig. 98: Changing the safety filter
Item
Description
Item
Description
1
Safety filter
4
Screw (4 x)
2
Maintenance cover
5
Fastening bracket (2x)
3
Filter holder
Tab. 78: Positions on the product
