Common welding settings:
Parameter Value Note
Current limit min
TIG: 2 A / MMA: 8 A, step 1 A
*
Current limit max
TIG: power source's nominal value /
MMA: power source's max. MMA current,
step 1 A
*
Remote control mode
OFF/ Remote / Torch (Default = OFF) When a remote control or a torch remote
control is selected, the welding current
adjustment on the control panel is dis-
abled.
Remote control min
Min = “Current limit min”, Max = “Current
limit max”
Remote control max
Min = “Current limit min”, Max = “Current
limit max”
Remote mode
Current / Channel (Default = Current) Select whether the remote control
adjusts welding current or memory chan-
nels.
Wireless remote
Pairing starts automatically when selec-
ted
New pairing information replaces the old
information.
Pairing status is shown as the settings
value.
TIG settings:
Parameter Value Note
Balance limit min
-99 ... 0, step 1 (Default =-60)
Balance limit max
0 ... +20, step 1 (Default = 0)
Lift TIG current
5 A ... 40 A / Auto, step 1 A (Default =
Auto = 10 A)
HF spark force
50 % ... 110 %, step 1 % (Default = 100 %)
Positive ignition current
30 % ... 150 % / Auto, step 1 % (Default =
Auto)
Positive ignition time
0 ms ... 50 ms / Auto, step 10 ms (Default
= Auto)
Negative ignition current
(ACDC): 100 % ... 300 % / Auto, Step 1 %
(Default = Auto)
Ignition current
(DC): 100 % ... 300 % / Auto, step 1 %
(Default = Auto)
Negative ignition time
(ACDC): 0 ms ... 950 ms / Auto, step 10 ms
(Default = Auto)
Ignition time
(DC): 0 ms ... 950 ms / Auto, step 10 ms
(Default = Auto)
Slight upslope
OFF / ON (Default = OFF)
Startup level
5 % ... 40 %, step 1 % (Default = 10 %)
Downslope cut level
5 % ... 40 %, step 1 % (Default = 10 %)
2T downslope cut
OFF / ON (Default = OFF)
© Kemppi
45
1921940 / 2140
