MasterTig 535ACDC
Operating manual - EN
Parameter Value Note
Nonlinear downslope
0 % ... 50 %, step 1 % (Default = 0 %)
Current freezing
OFF / ON (Default = OFF)
TIG antifreeze
OFF / ON (Default = OFF)
AC phase swap current
5 A ... 20 A / Auto
MMA settings:
Parameter Value Note
Welding current
Min/Max = Normal welding current limits
Hot start
-10 ... +10, step 1 (Default = 0)
Arc force
-10 ... +10, step 1 (Default = 0)
MMA antifreeze
OFF / ON (Default = ON)
VRD mode
OFF / ON (Default = OFF) This setting can be locked so that the
user cannot change it. In the equipment
models where the VRD mode is locked
permanently to ON (e.g. AU model), the
VRD option is still visible in the settings,
but it cannot be changed.
System settings:
Parameter Value Note
Gas test
Gas test time:0 s ... 60 s, step 1 s (Default
= 20 s)
Activating this starts the gas test with
default time. Time can be changed by
turning the control knob. Gas test can be
stopped by pressing the control knob
again.
Water cooler
OFF / Auto / ON (Default = Auto)
Cooler flow sensor
OFF / ON (Default = ON)
Brightness
10 % ... 100 %, step 1 % (Default = 100 %)
Weld data time
OFF / 1 s ... 10 s, step 1 s (Default = 5 s)
Screen saver time
OFF / 1 min ... 120 min, step 1 min
(Default = 5 min)
Display off time
OFF / 1 min ... 120 min (Default = 5 min)
Screen saver image
Default = Kemppi logo An alternative screen saver image can be
used. For more information, refer to
"Screen saver" on page48.
Show Weld Assist
ON / OFF (Default = ON)
Date
Date setting (DD/MM/YYYY)
Time (24h)
Time setting (HH:MM)
Language
Language setting
Factory reset...
Cancel / Start (Default = Cancel) Settings item that activates the factory
reset to restore factory settings on the
device. Once the factory reset is com-
plete, the power source must be restar-
ted manually.
© Kemppi
46
1921940 / 2140
