Kemppi X8 MIG User Manual

X8 MIG WELDER 2.4 Operation
2.4.2.2 Calibrating arc voltage
X8 MIG Welder measures the voltage of the welding arc and the voltage loss in the interconnection cable
and welding gun. After calibration, the power source calculates the arc voltage, if the voltage sensing cable is
not connected.
Figure 28: Calibration of the welding cables
Proceed as follows:
1.
Ensure that the measurement cable connects the wire feeder and the power source.
2.
Connect the voltage sensing cable from the wire feeder to the welding piece.
OPERATING MANUAL | EN 105
©
KEMPPI | 2018-09-28
