Kemppi X8 MIG User Manual

X8 MIG WELDER 2.7 Technical data
Feature Description Value
Operating temperature range -20…+40°C
Storage temperature range -40…+60°C
Pistol grip handle Yes
Changeable neck Yes
Rotating neck Yes
Length x (see figure
below)
101mmNeck dimensions
Height y (see figure
below)
86mm
Neck angle ɑ (see figure below) 50°
Standards IEC 60974-7
Figure 57: Neck dimensions and angle
2.7.8 X8 MIG Gun 300-g
Feature Description Value
Welding process MIG/MAG
Method of guidance Manual
Type of cooling Gas
Type of connection Kemppi
Wire diameters 0.8 - 1.2mm
@60% (MIXED GAS) 300A
@100% (MIXED
GAS)
-
@60% (CO
2
) -
Load capacity
@100% (CO
2
) -
Fe 0.8 - 1.2mm
Fe-MC/FC 0.9 - 1.2mm
Ss 0.8 - 1.2mm
Ss-MC/FC 0.9 - 1.2mm
Filler wires
Al 0.8 - 1.2mm
OPERATING MANUAL | EN 183
©
KEMPPI | 2018-09-28
