Kemppi X8 MIG User Manual

X8 MIG WELDER 2.7 Technical data
Feature Description Value
Operating temperature range -20…+40°C
Storage temperature range -40…+60°C
Pistol grip handle Yes
Changeable neck Yes
Rotating neck Yes
Length x (see figure
below)
132mmNeck dimensions
Height y (see figure
below)
110mm
Neck angle ɑ (see figure below) 50°
Standards IEC 60974-7
Figure 59: Neck dimensions and angle
2.7.10 X8 MIG Gun 420-w
Feature Description Value
Welding process MIG/MAG
Method of guidance Manual
Type of cooling Liquid
Coolant flow rate 1l/min
Coolant pressure (max) 5bar
Type of connection Kemppi
Wire diameters 0.8 - 1.6mm
@60% (MIXED GAS) -
@100% (MIXED
GAS)
420A
@60% (CO
2
) -
Load capacity
@100% (CO
2
) -
Fe 0.8 - 1.6mm
Fe-MC/FC 0.9 - 1.6mm
Filler wires
Ss 0.8 - 1.6mm
OPERATING MANUAL | EN 185
©
KEMPPI | 2018-09-28
