X8 MIG WELDER 2.2 System structure
6. Measurement cable
7. Strain relief pin
2.2.2 X8 Wire Feeder
This section describes the structure of X8 Wire Feeder.
Main parts
1. Top cover
Caution:
Keep the wire feeder top cover closed during welding to reduce the risk of injury or an electric
shock. Keep the top cover closed also at other times to keep the wire feeder insides clean.
2. Handle
Caution:
The handle is only intended for short distance manual carrying. Use Wire Feeder Hanger for
Boom for lifting or hanging the wire feeder.
3. Top cover latch
4. Cable cabinet door
5. Cable cabinet latch
6. Control panel
7. Strain relief
8. Strain relief latch
9. Gun holder mount
OPERATING MANUAL | EN 15
©
KEMPPI | 2018-09-28
