Kemppi X8 MIG User Manual

X8 MIG WELDER 2.2 System structure
2.2.3 X8 MIG Guns
Gas-cooled gun
13
108
65 7 9
4
3
11
2
12
1
1. Gas nozzle
2. Insulating bush
3. Contact tip
4. Contact tip adapter
5. Neck
6. Neck tightener
7. Work light
Press the trigger lightly to switch on the light.
8. Handle cover plate
Covers the handle if the remote control is not used.
9. Trigger
10. X8 Gun Remote Control
The remote control is an optional accessory.
11. Trigger on the pistol grip handle
OPERATING MANUAL | EN 20
©
KEMPPI | 2018-09-28
