Kemppi X8 MIG User Manual

X8 MIG WELDER 2.7 Technical data
Feature Description Value
Gun connection Kemppi
Wire feed mechanism 4-roll, twin-motor
Diameter of feed rolls 32mm
Filler wires Fe 0.6-2.4mm
Ss 0.6-2.4mm
MC/FC 0.8-2.4mm
Al 0.8-2.4mm
Wire feed speed 0.5-25m/min
Wire spool weight (max) 20kg
Wire spool diameter (max) 300mm
Shielding gas pressure (max) p
max
0.5MPa
Operating temperature range -20…+40°C
Storage temperature range -40…+60°C
EMC class A
Degree of protection IP23S
External dimensions LxWxH 640x220x400mm
Weight without accessories 11.2kg
Wireless communication type
• Transmitter frequency and power
2.4GHz Bluetooth
• 2402-2480MHz 19dBm
Standards IEC60974-5,10
2.7.6 X8 Control Pad
Feature Description Value
Operating voltage U
1
12V
Operating temperature range -20…+40°C
Storage temperature range -40…+60°C
Degree of protection IP54
External dimensions LxWxH 200x130x33 mm
Weight without accessories 0.89kg
Typical battery operation time 15-24h
Battery type Li-ion
Rated battery voltage 7.2V
Rated battery capacity 6.2Ah
Rated charging current 1A
OPERATING MANUAL | EN 181
©
KEMPPI | 2018-09-28
