Kemppi X8 MIG User Manual

X8 MIG WELDER 2.7 Technical data
Feature Description Value
Ss-MC/FC 0.9 - 1.6mm
Al 0.8 - 1.6mm
Operating temperature range -20…+40°C
Storage temperature range -40…+60°C
Minimum cooling power at 1.6l/min*
1.9kW
Minimum flow rate 1.6l/min
Pistol grip handle Yes
Changeable neck No
Rotating neck No
Length x (see figure
below)
132 / 232 mmNeck dimensions
Height y (see figure
below)
104mm
Neck angle ɑ (see figure below) 50°
Standards IEC 60974-7
*Gun length 5 m
Figure 60: Neck dimensions and angle
2.7.11 X8 MIG Gun 520-w
Feature Description Value
Welding process MIG/MAG
Method of guidance Manual
Type of cooling Liquid
Coolant flow rate 1l/min
Coolant pressure (max) 5bar
Type of connection Kemppi
Wire diameters 0.8-1.6mm
Load capacity @60% (MIXED GAS) -
OPERATING MANUAL | EN 186
©
KEMPPI | 2018-09-28

Kemppi X8 MIG Specifications

General

Brand	Kemppi
Model	X8 MIG
Category	Welding System
Language	English
