Kemppi X8 MIG User Manual

X8 MIG WELDER 2.7 Technical data
ValueFeature Description
500 A 500 A MV
No-load voltage (MIG & MMA) U
0peak
76-92VDC 76-92VDC
No-load voltage (MMA) U
r peak
72-86VDC 72-86VDC
Fuse 220-230V - 63A
380-460V 32A 32A
Output 40%ED - -
60%ED 500A 500A
100%ED 400A 400A
Welding current and voltage range MIG@220V -
20A/14V-500A/55V
MIG@380V 20A/14V-500A/55V 20A/14V-500A/55V
Welding current and voltage range MMA@220V -
15A/20V-500A/57V
MMA@380V 15A/20V-500A/57V 15A/20V-500A/57V
Welding voltage (max) 57V 57V
Power factor at max current P.F. 0.82-0.90 0.80-0.90
Efficiency at max current ƞ 89-91% 89-91%
Operating temperature range -20…+40°C -20…+40°C
Storage temperature range -40…+60°C -40…+60°C
EMC class A A
Minimum short-circuit power S
SC
of
supply network
S
SC
5.1MVA 5.1MVA
Degree of protection IP23S IP23S
External dimensions LxWxH 921x348x795mm 921x348x795mm
Weight without accessories 95kg 95kg
Voltage supply for auxiliary devices U
aux
48V/500W 48V/500W
Voltage supply for cooling unit U
cu
- 220-230V ±10%
380-460V ±10% 380-460V ±10%
Recommended generator power (min)
S
gen
35kVA 35kVA
Wireless communication type
• Transmitter frequency and power
2.4GHzWiFi &
Bluetooth
2.4GHz Bluetooth and
WLAN
• 2400-2483.5MHz
20dBm
2.4GHzWiFi &
Bluetooth
2.4GHz Bluetooth and
WLAN
• 2400-2483.5MHz
20dBm
Wired communication type Ethernet & USB Ethernet & USB
OPERATING MANUAL | EN 177
©
KEMPPI | 2018-09-28
