Kemppi X8 MIG User Manual

X8 MIG WELDER 2.7 Technical data
Feature Description Value
Type of cooling Liquid
Coolant flow rate 1l/min
Coolant pressure (max) 5bar
Type of connection Kemppi
Wire diameters 1.2 - 2.4mm
@60% (MIXED GAS) -
@100% (MIXED GAS) 600A
@60% (CO
2
) -
Load capacity
@100% (CO
2
) -
Fe 1.2 - 2.4mm
Fe-MC/FC 1.2 - 2.4mm
Ss 1.2 - 1.6mm
Ss-MC/FC 1.2 - 1.6mm
Filler wires
Al 1.2 - 2.4mm
Operating temperature range -20…+40°C
Storage temperature range -40…+60°C
Minimum cooling power at 1.6l/min* IEC60974-7
1.9kW
Minimum flow rate 1.6l/min
Pistol grip handle Yes
Changeable neck No
Rotating neck No
Neck dimensions 251mm
72mm
Neck angle 30°
Standards IEC 60974-7
*Gun length 5 m
Figure 62: Neck dimensions and angle
OPERATING MANUAL | EN 188
©
KEMPPI | 2018-09-28
