X8 MIG WELDER 2.3 Installation
Figure 3: Interconnection cabling for power source and wire feeder
Table 3: Color codes
Welding current cable
Shielding gas hose
Control cable
Measurement cable
Coolant input and output hoses
OPERATING MANUAL | EN 54
©
KEMPPI | 2018-09-28
