X8 MIG WELDER 2.3 Installation
The led on the power source begins to blink when it is searching for Control Pad.
The serial numbers of the nearby available wire feeders or power sources appear on Control Pad's
display.
Note:
When there are wire feeders connected to the welding system, pressing the wireless pairing
button allows you to connect Control Pad to a wire feeder. When there are no wire feeders
connected to the system, Control Pad allows you to connect to a power source.
Figure 4: Connecting to wire feeder Figure 5: Connecting to power source
b) Move focus to select the connection and press the green button.
Note:
OPERATING MANUAL | EN 56
©
KEMPPI | 2018-09-28
