Kenwood eXcelon KDC-X789 - Audio Configuration and Setup; Audio Control Settings (KDC-X889;MP828); Audio Setup Configuration

12
|
English
General features
Function of the KDC-X889/KDC-MP828
Audio Control
1
Select the source for adjustment
Press the [SRC] button.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Select the Audio item for adjustment
Press the [VOL] knob.
Each time the knob is pressed, the items that can
be adjusted switch as shown below.
4 Adjust the Audio item
Turn the [VOL] knob.
Adjustment Item Display Range
Rear Volume *
1
"Rear Volume" 0 — 35
Subwoofer level*
2,3
"Sub-WLevel" –15 — +15
Balance "Balance" Left 15 — Right 15
Fader*
3
"Fader" Rear 15 — Front 15
Exit Audio Control mode
• *
1
You can control this item when "2 ZONE" of <Audio
Setup> (page 13) is set to "ON".
• *
2
You can control this item when <Subwoofer
Output> (page 14) is set to "SW ON".
• *
2
You can control this item when Speaker Select
Subwoofer of <Sound Management system> (page
15) is set to any item other than "None".
• *
3
You can control this item when "2 ZONE" of <Audio
Setup> (page 13) is set to "OFF".
5 Exit Audio Control mode
Press any button.
Press the button which is not [VOL] knob and
[ATT]/[ANG] button.
Function of the KDC-MP7028/KDC-MP728/KDC-
X789/KDC-MP628
Audio Setup
Setting the Sound system, such as Cross over
Network.
1 Select the source for adjustment
Press the [SRC] button.
2 Enter Audio Setup mode
Press the [VOL] knob for at least 1 second.
3 Select the Audio Setup item for adjustment
Press the [VOL] knob.
Each time the knob is pressed, the items that can
be adjusted switch as shown below.
4 Setup the Audio item
Turn the [VOL] knob.
Adjustment Item Display Range
Front High Pass Filter*
2
(KDC-MP728/MP628)
(KDC-MP7028/X789)
"HPF-F Fc"
Through/80/100/120/150
/180 Hz
Through/40/60/80/100/120/
150/180/220 Hz
Rear High Pass Filter*
2
(KDC-MP728/MP628)
(KDC-MP7028/X789)
"HPF-R Fc"
Through/80/100/120/150/
180 Hz
Through/40/60/80/100/120/
150/180/220 Hz
Low Pass Filter*
1,2
(KDC-MP728/MP628)
(KDC-MP7028/X789)
"LPF-SW"
60/80/120/Through Hz
50/60/80/100/120/
Through Hz
Subwoofer Phase*
1,2
"SW Phase" Reverse (180°)/ Normal (0°)
Volume offset "Vol-Offset" –8 — 0
Loudness "LOUD" OFF/ON
Dual Zone System "2 ZONE" OFF/ON
• Volume offset: Each source’s volume can be set as a
difference from the basic volume.
• Loudness: Compensating for low and high tones
during low volume.
• *
1
You can control this item when <Switching preout>
(page 43) is set to "SWPRE Sub-W". (KDC-MP728/
MP628 only)
• *
1
You can control this item when <Subwoofer
Output> (page 14) is set to "SW ON".
• *
2
You can control this item when "2 ZONE" of <Audio
Setup> is set to "OFF".
• Dual Zone System
Main source and sub source (Auxiliary input) output
Front channel and Rear channel separately.
- The channel of sub source is set up by <Dual Zone
System Setting> (page 45).
- Main source is selected by [SRC] button.
- The volume of Front channel is adjusted by [VOL]
knob.
- The volume of Rear channel is adjusted by <Audio
Control> (page 10).
- The Audio Control has no effect on sub source.
• The Dual Zone System can be used with the Auxiliary
input sources shown below.
- Internal auxiliary input
5 Exit Audio Setup mode
Press [VOL] knob for at least 1 second.
