Output Connection
Selects the tester output connection to which the results are to be sent,
available options are:
RS232
This sends the data to the RS232 serial port (9 way D connection on the
tester) for connection using a compatible serial cable. Select this option
for downloading to PAT software.
USB
This sends the data to the USB port on the front of the tester for
connection to a compatible memory stick.
Baud Rate
If available this option selects to the Baud Rate at which the data is sent,
possible values are 9600, 19200 or 28800. Leave default set to 9600
for downloading to PAT software.
Download Format
This field shows the format choices available depending upon the
destination selected.
For downloading to a PC the user has the option of sending data in a
SIMPLY PATS format, compatible with Kewtech PAT Manager software,
SSS format - Seaward Super String, compatible with Seaward PAT
software and Robin / Fluke’s Power Pat Plus, Certificate - downloads
results in non-ASCII certificate format, Summary - downloads a
summary of results.
For downloading to a generic A4 printer the user has the option of
sending data as a certificate, or a list, or as pass/fail labels. In the
certificate format the user has the option to produce one certificate per
page or to produce continuous printouts.
HOW TO DOWNLOAD DATA
For downloading to a roll printer, including ‘till roll’ and thermal printers
the user has the option of sending data as a continuous list, a certificate,
a summary or as pass/fail labels. When using a compatible thermal roll
printer the pass/fail labels will produce appliance numbers in a number
and barcode format. However, the restrictions of paper width means that
appliance numbers representing more than 12 characters cannot be printed
and a numbered label will print instead. Testcodes are accommodated
since these are displayed as two lines of 10 characters each.
Use repeated presses of the enter button to show desired settings for
download format. If appropriate the option field will illuminate. Use
repeated presses of the Enter button to show desired settings.
When the download options are set highlight the OK field and press the
enter button or select the OK Fast key to display the following menu:-
Use the cursor keys to highlight the required search parameters and press
Enter to select the desired option.
Appliance Number
Enter an Appliance number to search for specific results. If the Appliance
number field is left blank then the character ∗ will be inserted, indicating to
search for all of the appliances.
