FACTORY-SET TEST SEQUENCES
TESTCODE TABLES
Name
Earth
Bond
Insulation Leakage
Touch
Leakage
Flash
230V HH/PORT 1 0.1Ω 1.0MΩ 0.75mA SKIP SKIP
230V HH/PORT 2 SKIP 2.0MΩ 0.25mA SKIP SKIP
IT EQUIPMENT 1 0.1Ω 1.MΩ SKIP SKIP SKIP
IT EQUIPMENT 2 SKIP 2.0MΩ SKIP SKIP SKIP
230V MOV/STAT 1 0.1Ω 1.0MΩ 3.5mA SKIP SKIP
230V MOV/STAT 2 SKIP 2.0MΩ SKIP 0.25mA SKIP
230VLEAD (3M) 0.08Ω 1.0MΩ SKIP SKIP SKIP
230V LEAD (6M) 0.2Ω 1.0MΩ SKIP SKIP SKIP
230V LEAD (12M) 0.3Ω 1.0MΩ SKIP SKIP SKIP
230V HH/PORT NI 1 0.1Ω SKIP 0.75mA SKIP SKIP
230V HH/PORT NI 2 SKIP SKIP SKIP 0.25mA SKIP
110V HH/PORT 1 0.1Ω 1.0MΩ 0.75mA SKIP SKIP
110V HH/PORT 2 SKIP 2.0MΩ SKIP 0.25mA SKIP
110V MOV/STAT 1 0.1Ω 1.0MΩ 3.5mA SKIP SKIP
110V MOV/STAT 2 SKIP 2.0MΩ SKIP 0.25mA SKIP
110V LEAD (3M) 0.08Ω 1MΩ SKIP SKIP SKIP
110V LEAD (6M) 0.2Ω 1MΩ SKIP SKIP SKIP
110V LEAD (12M) 0.3 1MΩ SKIP SKIP SKIP
Appendix B Reference Information
Factory-set Test Sequences
All tests have visual test included
Extension lead tests include a Polarity check
Testcode Tables
The test sequence code is split into two 10-digit testcodes, this Appendix
describes how the two testcodes are broken down.
First Testcode:
Digit 1
Visual Inspection/
Polarity
Voltage
H
No Visual Inspection
No Polarity Test
230V
I
No Visual Inspection
No Polarity Test
230V
J
No Visual Inspection
Polarity Test
230V
K
No Visual Inspection
Polarity Test
230V
L
No Visual Inspection
No Polarity Test
115V
M
No Visual Inspection
No Polarity Test
115V
N
No Visual Inspection
Polarity Test
115V
O
No Visual Inspection
Polarity Test
115V
FACTORY-SET TEST SEQUENCES
TESTCODE TABLES
Digit 2 Earth Bond
0 Skip Earth Bond
1-9 Earth Bond Fault Limit (mΩ)
A 1.5 mΩ
B 2.5 mΩ
C 3.5 mΩ
D 4.5 mΩ
E 5.5 mΩ
F 6.5 mΩ
G 7.5 mΩ
H 8.5 mΩ
I 9.5 mΩ
