HOW TO PRINT BARCODE LABELS AND TESTCODES
HOW TO PRINT BARCODE LABELS AND TESTCODES
How to use Setup
To set up the Tester, use the cursor keys to highlight the Setup option on
the Main Menu and press Enter to display the following menu: -
From this menu you can change the way the Tester will operate and also
change User levels and Sites. Use the cursor keys to highlight a function
and press Enter to select the desired option.
Edit Test Settings
This allows the user to add, modify, remove or confirm test settings that
can then be selected during automatic testing.
Use the cursor keys to highlight a Test Setting and press Enter to enter the
TEST SETTING EDITOR.
Test Settings Editor
The TEST SETTINGS EDITOR allows the test sequence for the selected test
to be examined and changed if required.
Use the cursor keys to highlight a field to be changed and press Enter to
select the desired option.
Name
Each test sequence is given a name. This is to help the user when selecting
test sequences during automatic testing. When Name is highlighted press
the Enter button, then use the keyboard to enter a new name for the Test
Sequence (of up to 15 characters) and press Enter to confirm.
---------------------TEST SETTINGS EDITOR-------------------
OUTPUT LIMIT DUR NUM
SOCKET 230V
VISUAL YES 1
EARTH BOND 25A∼ 0.10Ω 5s 1
INSULATION 500V= 1.00MΩ 5s 1
SUB LEAKAGE SKIP
LEAKAGE 230V∼ 0.75mA 5s 1
TOUCH LEAKAGE SKIP
POLARITY SKIP
TESTCODE 1: I1C700321
TESTCODE 2: S121111111
NAME: 230V HH / PORT 1
PRINT TESTCODES
OK
