Appliance Test Results
It is possible to view the results obtained for a certain appliance by
highlighting the appliance number and pressing the Enter button.
A fast key is available to VIEW COMMENTS.
Use the Red button to return to the previous menu.
HOW TO VIEW TEST RESULTS
HOW TO PERFORM MANUAL TESTS
Manual mode provides the user with direct access to the tests. In this
mode individual tests can be selected and performed. Appliance number,
site, location, user can still be assigned to appliances if it is required to
store the result.
Entering Manual Mode
Use the Fast key to select Manual Mode from the Main Menu.
Note
To store tests in memory from Manual mode you must first select Create
Appliance No., perform the tests required for the EUT. When you have
completed the required tests select Enter Comments/Save Results, upon
leaving this option the Tester will now store the results. Note that Enter
Comments option is not displayed until there is something to store.
The manual tests and other options available are shown in the table below: -
Press the appropriate key to select a test or option.
HOW TO VIEW TEST RESULTS
HOW TO PERFORM MANUAL TESTS
----------MANUAL TEST SELECTION--------------
A..CREATE APPLIANCE NO.
S..CHANGE 230V/115V OP SOCKET
1..VISUAL CHECK
2..EARTH BOND TEST
3..INSULATION TEST
4..SUB LEAKAGE TEST
5..LEAKAGE TEST
6..FLASH TEST
7..TOUCH LEKAGE TEST
8..POLARITY TEST
C.ENTER COMMENTS & STORE RESULTS
