HOW TO PRINT BARCODE LABELS AND TESTCODES
Test Parameter Fields
By selecting one of the test parameter fields from the TEST SETTINGS
EDITOR, a list of options for that field will be displayed INSULATION Test for
example: -
Store Settings
Use the cursor keys to highlight the OK and press Enter or select the OK
Fast key to save the settings and return to the previous menu. Pressing
the Red Button will abort all of the changes made and return to the previous
menu.
Print Testcodes
The Testcodes can be printed (using a compatible printer - see Chapter 6).
Use the cursor keys to highlight PRINT TESTCODES then press the Enter
button to start the print. The following message will be displayed:-
On completion of printing, the TEST SETTINGS EDITOR menu is displayed.
Press the Red Button to return to the TEST SETTINGS EDITOR menu.
When you first enter this menu all of the previous values and one of the Test
Parameter columns are highlighted. Use the cursor left and right keys to
highlight the Test Parameter to be changed and then use the cursor up and
down keys to highlight the required setting. Use this process for each Test
Parameter.
Use the Enter button or OK Fast key to save the settings and return to the
TEST SETTINGS EDITOR. Press the Red button to abort changes made to
the settings and return to the TEST SETTINGS EDITOR.
Earth Bond Limit Calculator
Earth Bond tests have an additional Fast Key; LIMIT CALC. Selecting this
enables the User to set an accurate Earth Bond Test limit by specifying the
cable parameters.
Testcodes
Selections made in the Test Parameter Fields will automatically set the
correct Testcode. Alternatively entering a Testcode will automatically set the
correct Test Parameters for that Testcode.
PRINTING TESTCODES
PRESS THE RED BUTTON TO
ABORT
HOW TO PRINT BARCODE LABELS AND TESTCODES
