TESTCODE TABLES
Digit 3
Earth Bond
Multiplier
Current
1 x1 4A
2 x10 4A
3 x100 4A
4 x1000 4A
5 x1 10A
6 x10 10A
7 x100 10A
8 x1000 10A
A x1 25A
B x10 25A
C x100 25A
D x1000 25A
E x1 100mA a.c.
F x10 100mA a.c.
G x100 100mA a.c.
H x1000 100mA a.c.
I x1 +200mA
J x10 +200mA
K x100 +200mA
L x1000 +200mA
M x1 -200mA
N x10 -200mA
O x100 -200mA
P x1000 -200mA
Q x1 + - 200mA
R x10 + - 200mA
S x100 + - 200mA
T x1000 + - 200mA
U Reserved
V Reserved
W Reserved
X Reserved
Digit 4 Insulation Voltage
0 Skip
1 0.5MΩ 250V d.c.
2 1.0MΩ 250V d.c.
3 2.0MΩ 250V d.c.
4 4.0MΩ 250V d.c.
5 7.0MΩ 250V d.c.
6 0.5MΩ 500V d.c.
7 1.0MΩ 500V d.c.
8 2.0MΩ 500V d.c.
9 4.0MΩ 500V d.c.
A 7.0MΩ 500V d.c.
B 10.0MΩ 250V d.c.
C 50.0MΩ 250V d.c.
D 10.0MΩ 500V d.c.
E 50.0MΩ 500V d.c.
Digit 5 Sub-Leakage
0 Skip
1 0.25mA
2 0.50mA
3 0.75mA
4 2.50mA
5 3.50mA
6 7.00mA
7 9.90mA
8 15.0mA
9 1.00mA
