TESTCODE TABLES
Digit 6
1
Not used (Set to 0)
0 Reserved
1 Reserved
2 Reserved
3 Reserved
4 Reserved
Digit 7 Leakage
0 Skip
1 0.25mA
2 0.50mA
3 0.75mA
4 1.50mA
5 2.25mA
6 2.50mA
7 3.00mA
8 3.50mA
9 9.90mA
A 1.00mA
Digit 8 Touch Leakage
0 Skip
1 0.25mA
2 0.50mA
3 1.00mA
Digit 9 Earth Bond Test Duration
1 2s : add 0.0 to the earth bond limit
2 5s : add 0.0 to the earth bond limit
3 10s : add 0.0 to the earth bond limit
4 30s : add 0.0 to the earth bond limit
5 2s : add 0.1 to the earth bond limit
6 5s : add 0.1 to the earth bond limit
7 10s : add 0.1 to the earth bond limit
8 30s : add 0.1 to the earth bond limit
9 2s : add 0.2 to the earth bond limit
A 5s : add 0.2 to the earth bond limit
B 10s : add 0.2 to the earth bond limit
C 30s : add 0.2 to the earth bond limit
D 2s : add 0.3 to the earth bond limit
E 5s : add 0.3 to the earth bond limit
F 10s : add 0.3 to the earth bond limit
G 30s : add 0.3 to the earth bond limit
H 2s : add 0.4 to the earth bond limit
I 5s : add 0.4 to the earth bond limit
J 10s : add 0.4 to the earth bond limit
K 30s : add 0.4 to the earth bond limit
Digit 10 Insulation Test Duration
1 2s
2 5s
3 10s
4 30s
