◆Battery Power Bar Settings
VOL represents voltage settings. Each bar represents a voltage value. Each of the 5 values is to be
entered one by one.
For example, VOL 1 is the first bar
voltage value, the default value is 31.5V. Press
UP or DOWN button to increase or decrease the bar value and press ON/OFF button to store a
changed setting and access the second bar. Likewise, you can set the values in the same manner for
other bars. After values for 5 bars are entered completely, press ON/OFF to confirm and return to the
previous menu.
Battery Bar Settings
◆
Assist Level Settings
SCA represents assist level settings.
Assist Level mode options
There are 8 assist level modes: 0-3, 1-3, 0-5, 1-5, 0-7, 1-7, 0-9, 1-9. The default mode is 0-5.
Press the UP/DOWN button to increase or decrease until the desired mode is displayed.
Press the ON/OFF button and access the assist level ratio settings automatically.
“1-5” flash
Assist Level Mode Interface
