Key-Disp KD21C - Error Code Definitions; List of Error Codes; Personalized Parameter Settings Symbols; Mapping Settings Items to Symbols

21
Attached list 1: Error code definition
Attached list 2: Personalized Parameter settings
Attached list 3：Assist level ratio defaults
Level
PAS
Level mode
1
2
3
4
5
6
7
8
9
0-3/1-3
50%
74%
92%
—
—
—
—
—
—
0-5/ 1-5
50%
61%
73%
85%
96%
—
—
—
—
0-7/ 1-7
40%
50%
60%
70%
80%
90%
96%
—
—
0-9/ 1-9
25%
34%
43%
52%
61%
70%
79%
88%
96%
Error Code
Definition
21
Current Abnormality
22
Throttle Abnormality
23
Motor Phase Abnormality
24
Motor Hall Signal Abnormality
25
Brake Abnormality
30
Communication Abnormality
No.
Settings item
Symbol
1
Battery Power Bar Settings
2
Power assistant level Settings
3
Over-current Cut Settings
4
Power Assistant Sensor Settings
5
Speed Sensor Settings
6
Throttle Function Settings
7
System Settings
8
Power-on Password Settings
