Software information interface
Note: The software version number is only used for Kds internal
traceability.
Quality Assurance and Warranty Scope
Ⅰ Warranty
（1）The warranty will be valid only for products used in normal usage and conditions.
（2）The warranty is valid for 24 months after the shipment or delivery to the customer.
Ⅱ Others
The following items do not belong to our warranty scope.
（1）The display is demolished.
（2）The damage of the display is caused by wrong installation or operation.
（3）Shell of the display is broken when the display is out of the factory.
（4）Wire of the display is broken.
（5）The fault or damage of the display is caused by the force majeure (e.g., Fire,
Earthquake, etc.).
（6）Beyond Warranty period.
Connection Layout
Connector line sequence
Line sequence table
Line
Color Function
1
Red（VCC）
+
2
Blue（K）
Lock
3
Black（GND）
-
4
Green（RX）
RX
5
Yellow（TX）
TX
■Some wire use the water-proof connector, users can not see the inside
color.
