Key-Disp KD86 - Operation Cautions; Attached List 1：Error Code Definition; Attached List 2：Default Value Table of Power Assist Level Ratio

16
Operation Cautions
Be careful of safe use. Don’t attempt to release the connector when battery is on power.
●Try to avoid hitting.
●Do not modify system parameters to avoid parameters disorder.
●Make the display repaired when error code appears.
This operating instruction is a general-purpose version. Some of the version for the
display software will be different from the specification, which should depend on the actual
use version.
■If no operation is performed within one minute, the display will automatically
exit the setting state.
Attached list 1：Error code definition
Error
Definition
21
Current Abnormality
22
Throttle Abnormality
23
Motor phase Abnormality
24
Motor Hall Signal Abnormality
25
Brake Abnormality
30
Communication Abnormality
Attached list 2：Default value table of power assist
level ratio
PAS Level
PAS
Level selection
1 2 3 4 5 6 7 8 9
0-3/1-3 50% 74% 92% — — — — — —
0-5/ 1-5 50% 61% 73% 85% 96% — — — —
0-7/ 1-7 40% 50% 60% 70% 80% 90% 96% — —
0-9/ 1-9 25% 34% 43% 52% 61% 70% 79% 88% 96%
