Key-Disp KD86 - Product Model; Specifications; Appearance and Size; Function Summary

1
Product Model
Intelligent TFT display for E-bike; model: KD86
Specifications
●36V/48V/52V Power Supply
●Rated working current:：50mA
●The maximum working current： 200mA
●Off leakage current： <1μA
●Operating temperature：-20～60℃
●Storage temperature：-30～70℃
Appearance and Size
Display appearance and dimension drawing (unit: mm)
Function Summary
KD86 can provide a lot of functions to fit your needs. The indicating contents are as
follows:
●Battery indicator
