Local Operations 5
Keysight 11713D/E Operating and Service Manual 49
3 Set TTL mode
(only for
11713E)
a On CONFIGURATION MENU
screen, press TTL ON/OFF softkey.
b On TTL MODE ON/OFF screen,
scroll to highlight the TTL option or
Non TTL (e.g. TTL option).
c Press Set softkey to assign
highlighted voltage.
d On the next screen, press OK
softkey to confirm decision or
press Cancel softkey to cancel.
e Selection is marked <*>.
f To exit this screen, press Back
softkey.
Item Action Illustration
