5Local Operations
50 Keysight 11713D/E Operating and Service Manual
4 Select voltage
type (only for
11713E)
a On CONFIGURATION MENU
screen, press Voltag. LEVEL
softkey.
b On OUTPUT VOLTAGE screen,
scroll to highlight the desired
voltage (e.g. +5V).
c Press Set softkey to assign
highlighted voltage.
d On the next screen, press OK
softkey to confirm decision or
press Cancel softkey to cancel.
e Output voltage assigned is marked
<*>.
f To exit this screen, press Back
softkey.
Item Action Illustration
