Step 3: Configure the 11713D/E connections to attenuators and switches
1 Determine the interface cable option of the 11713D/E.
2 Determine the DC connector option of the attenuator(s) or switch(es).
3 Check for compatibility using Table 1-3 for programmable attenuators and Table 1-2 for
switches:
Table 5-1 Connection between 11713D/E and programmable attenuators
11713D/E Attenuators (Option)
Option 001
8494G/H, 8495G/H, 8496G/H, 8495K, 8497K (Option 016)
84904K/L/M, 84905M, 84906K/L, 84907K/L, 84908M (No option)
Option 101 8494G/H, 8495G/H, 8496G/H, 8495K, 8497K (Option 060)
Table 5-2 Connection between 11713D/E and switches
11713D/E Switches (Option)
Option 001 8766K, 8767K/M, 8768K/M (Option 016)
Option 101 8766K, 8767K, 8768K, 8769K (Option 060)
Option 102 P9400A/C
Option 103 P9402A/C
Option 104 U9400A/C
Option 105 U9397A/C
Option 201
8763A/B/C, 8764A/B/C, 8762A/B/C/F (No option)
8765A/B/C/D/F (Option 305/310/315/324)
N1810UL/TL, N1811TL, N1812UL (Option
[a]
202)
87104A/B/C/D, 87204A/B/C, 87106A/B/C/D, 87206A/B/C (Option 100)
L7104A/B/C, L7204A/B/C, L7106A/B/C, L7206A/B/C (Option 100)
87406B, 87606B (Option 100)
87222C/D/E, L7222C (Option 100)
P9404A/C
Option 301 8765A/B/C/D/F (Option 005/010/015/024)
Option 401
87106A/B/C/D, 87206A/B/C (Option 161)
L7106A/B/C, L7206A/B/C (Option 161)
87406B, 87606B (Option 161)
Option 501
N1810UL/TL, N1811TL, N1812UL (Option
[a]
201)
Option 601
87104A/B/C/D, 87204A/B/C (Option 161)
L7104A/B/C, L7204A/B/C (Option 161)
Option 701 8769M (Option 016)
Option 801 87222C/D/E, L7222C (Option 161)
