A Rack Mounting the Counter
114 Keysight 53150A/151A/152A Operating Guide
Rack Mounting the Counter
You can mount the Counter in a standard 19-inch cabinet using one of two
optional kits available from Keysight:
– Option 1CM Rack Mount Kit (Keysight 53150-67001 Rack Adapter Kit) for
single instrument (Half Module) rack mounting. Instructions and mounting
hardware are included with the rack-mounting kit.
– Keysight 5061-9694 Lock Link Kit for two-instrument, side-by-side rack
mounting. Instructions and mounting hardware are included with the
rack-mounting kit. (Two Option 1CM Rack Mount Kits are also required when
mounting two instruments.)
To rack-mount the Counter, you must first remove the front and rear rubber
bumpers, the carrying handle, and the handle pivots:
1 Rotate the handle to its vertical position, pull the ends outward, and set
it aside.
NOTE
Unlike the hardware used elsewhere in this instrument, all hardware used to
attach the rack mounts and the handle pivots is metric.
