Rack Mounting the Counter A
Keysight 53150A/151A/152A Operating Guide 115
2 To remove the rubber bumpers, lift the center of the top of the bumper
upward, stretch a corner of the bumper diagonally, then slide it off the end of
the Counter.
3 To rack-mount the Counter by itself, perform the steps shown in the following
illustration. (Refer to the instructions that are provided with the Rack Adapter
Kit for details.)
1 Rack Flange 3 Keysight 53150A/151A/152A Counter
2 Handle Pivot 4 Panel Filler (Adapter) Assembly
OPTIONS
1
3
4
2
2
To Next Page
