A Rack Mounting the Counter
116 Keysight 53150A/151A/152A Operating Guide
4 To rack-mount the Counter with another instrument side-by-side, obtain the
5061-9694 Lock Link Kit. (Refer to the instructions that are provided with the
Lock Link Kit for details.)
1
2
3
3
2
4
5
1 Lock Links 4 Keysight 53150A/151A/152A Counter
2 Rack Flange 5 Second Keysight 53150A/151A/152A Counter
or other half-rack-size instrument
3 Handle Pivot
