2 Operating Your Frequency Counter
96 Keysight 53150A/151A/152A Operating Guide
5 Press the Enter key to select profile number 3.
Power Correction is enabled using profile number 3, and the measurement
display returns. The power reading now includes an adjustment for the loss
incurred at the measured frequency. The amount of the adjustment is derived
from the loss and frequency values in the data points in the selected profile. A
lower-case letter “c” is shown in the hundredths position of the
power-measurement display to indicate that Power Correction is enabled.
Ch 2
Freq
Pwr
dBm
NOTE
Pressing the Enter key when the number of a power-correction profile
(1-9) is displayed selects that profile, enables Power Correction, and exits the
Menu. If you intend to enter data in the currently displayed profile, press the
right-arrow key instead of the Enter key to select the power-correction profile
without exiting the Menu.
You can also select a power-correction profile by pressing the right- or
left-arrow key (instead of the Enter key). When you press either arrow key, you
do not exit the Menu. As the next example shows, you should select a profile
with the right-arrow key when you intend to enter or change the loss and/or
frequency values in the selected profile. You should select the power-correction
profile with the left-arrow key if you are done working with the power-correction
settings, but you want to change settings for other functions in the Menu.
