HCOPy Subsystem
HCOPy:SDUMp:DATA?
Returns the display image in BMP format.
Parameter Typical Return
(none) <Block>
Return the image in BMP format: HCOP:SDUM:DATA?
The image is a grey-scale Windows .BMP which has fixed 2,110 bytes. The response format is
IEEE488.2 definite-length block data -- #N<length><imagebody>, where N is always 4 and <length> is
always 2,110, therefore 2,116 bytes in total.
3îîSCPI Programming Reference
132 Keysight AC6800B Series Operating and Service Guide
